1. Probe Model: GE RIC5-9-D 2. Fault Detection Results: Outer skin color of the cable changed Skin color of crystal side strain relief changed Oil leaking ​3. Repair Parts Dome replacement 4. Before Repair & After Repair

1. Probe Model: GE 9L-D 2. Fault Detection Results: Lens detachment 2 elements weak, 7 elements dead 3. Repair Parts Lens replacement 4. Before Repair & After Repair Click to view more MYPRO news!

1. Probe Model: GE 3Sc-RS 2. Fault Detection Results: Crystal case wear 4 elements weak for echo test ​3. Repair Parts Crystal replacement 4. Before Repair & After Repair Click to view more MYPRO news!

1. Probe Model: Aloka UST-9124  2.Fault Detection Results: Lens fall 34 elements dead 3. Repair Parts Crystal 4. Before Repair & After Repair Click to view more repair cases

1. Probe Model: Sonoscape VC6-2 2.Fault Detection Results: Color of the outer skin of cable changed;  26 elements weak for capacitance test 3. Repair Parts Crystal 4. Before Repair & After Repair

1. Probe Model: Philips L12-3 for HD6 2.Fault Detection Results: Color of the outer skin of cable changed;  Strain relief for crystal side broken;  Lens broken 3. Repair Parts Crystal Lens Strain Relief of Crystal Side 4. Before Repair & After Repair

1. Probe Model: Philips C5-1 for CX50 2.Fault Detection Results: No lens;  Color of the outer skin of cable changed;  Color of the strain relief for crystal side changed;  The capacitance test shows 5 elements weak, 3 elements weak without crystal;  2 elements weak and 2 elements missing for echo test;  There is interference when pressing the crystal during operation on machine, and the image changes when twisting the cable 5 cm away from crystal. ​3. Repair Parts Crystal Cable Strain Relief of Crystal Side 4. Before Repair & After Repair

1. Probe Model: Toshiba PVM-375AT for SSA-550A 2.Fault Detection Results: Crystal housing craze Outer skin of cable is aging and turning yellow, severely hardening Lens is aging There is dark area and obvious interference in air scan image ​3. Repair Parts Crystal Cable Crystal case and housing Strain Relief of Crystal Side 4. Before Repair & After Repair
